4 - 10 EA3600 Network Connect Product Reference Guide
Calling the ScannerBlock
The following tags are required by the ScannerBlock. These tags must be assigned to the same I/O addresses of
the EA3600 for data transfers to work correctly (Table 4-3).
DataLength Length of data scanned in the Data byte array.
Data Array of 1024 bytes that contains the barcode data.
Table 4-3 ScannerBlock Required Tags
Tag Description
InScanObject Data type ScannerInStruct. Must be set to the input I/O address of the EA3600.
OutScanObject Data type ScannerOutStruct. Must be set to the output I/O address of the EA3600.
Table 4-2 Output Tags/Parameters for ScannerBlock (Continued)
Data Type Description
