ZKTeco SpeedFace-V3L User Manual

SpeedFace-V3L User Manual
Page | 51 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Baud Rate
There are 4 baud rate options at which the data
communicates with PC. They are: 115200 (default),
57600, 38400, and 19200.
The higher the baud rate, the faster is the
communication speed, but also less reliable.
Hence, a higher baud rate can be used when the
communication distance is short; when the
communication distance is long, choosing a lower baud
rate is more reliable.
PC Connection 8.3
Comm Key facilitates to improve the security of the data by setting up the
communication between the device and the PC. Once the Comm Key is set, a
password is required to connect the device to the PC software.
Tap PC Connection on the Comm. Settings interface to configure the
communication settings.
Function Description
Function Name Description
Comm Key
The default password is 0 and can be changed.
The Comm Key can contain 1-6 digits.
Baud Rate
It is the identification number of the device, which
ranges between 1 and 254.
If the communication method is RS485, you need to
input this device ID in the software communication
interface.

ZKTeco SpeedFace-V3L Specifications

General

Display type	LCD
Screen shape	Flat
Built-in display	Yes
Display diagonal	2.4 \
Display size (HxV)	240 x 320 mm
Internal memory	256 GB
Processor cores	2
Internal storage capacity	512 GB
Operating system installed	Linux
Type	Face recognition terminal
Access code reader	-
Authentication type	Biometric, Face recognition
Access chip/card reader	No
Face recognition distance	0.5 - 2 m
False Rejection Rate (FRR)	0.02 %
False Acceptance Rate (FAR)	0.01 %
International Protection (IP) code	IP65
Operating temperature (T-T)	-5 - 45 °C
Total megapixels	1 MP
RS-485 ports	1
Package weight	800 g

Weight and Dimensions

Depth	58.5 mm
Width	185 mm
Height	20 mm
Weight	300 g
