ZKTeco SpeedFace-V3L User Manual

SpeedFace-V3L User Manual
Page | 56 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Cloud Server Setting 8.5
Tap Cloud Server Setting on the Comm. Settings interface to connect with the
ADMS server.
Function Description
Function Name Description
Enable
Domain
Name
Server
Address
Once this mode is turned ON, the domain
name mode "http://... " will be used, such
as http://www.XYZ.com, while "XYZ"
denotes the domain name.
Disable
Domain
Name
Server
Address
The IP address of the ADMS server.
Server Port
Port used by the ADMS server.
Enable Proxy Server
The IP address and the port number of
the proxy server is set manually when the
proxy is enabled.

ZKTeco SpeedFace-V3L Specifications

General

Display type	LCD
Screen shape	Flat
Built-in display	Yes
Display diagonal	2.4 \
Display size (HxV)	240 x 320 mm
Internal memory	256 GB
Processor cores	2
Internal storage capacity	512 GB
Operating system installed	Linux
Type	Face recognition terminal
Access code reader	-
Authentication type	Biometric, Face recognition
Access chip/card reader	No
Face recognition distance	0.5 - 2 m
False Rejection Rate (FRR)	0.02 %
False Acceptance Rate (FAR)	0.01 %
International Protection (IP) code	IP65
Operating temperature (T-T)	-5 - 45 °C
Total megapixels	1 MP
RS-485 ports	1
Package weight	800 g

Weight and Dimensions

Depth	58.5 mm
Width	185 mm
Height	20 mm
Weight	300 g
