ZKTeco SpeedFace-V3L User Manual

SpeedFace-V3L User Manual
Page | 52 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Wi-Fi Settings 8.4
The device provides a Wi-Fi module, which can be built-in within the device
module or can be externally connected.
The Wi-Fi module enables data transmission via Wi-Fi (Wireless Fidelity) and
establishes a wireless network environment. Wi-Fi is enabled by default in the
device. If you don't need to use the Wi-Fi network, you can toggle the Wi-Fi to
disable the button.
Tap Wi-Fi Settings on the Comm. Settings interface to configure the Wi-Fi
settings.
 Searching the Wi-Fi Network
 WIFI is enabled in the device by default. Toggle the button to
enable or disable WIFI.
 Once the Wi-Fi is turned on, the device will search for the available Wi-Fi
within the network range.
 Tap on the required Wi-Fi name from the available list and input the
correct password in the password interface, and then tap Connect to
Wi-Fi (OK).

ZKTeco SpeedFace-V3L Specifications

General

Display type	LCD
Screen shape	Flat
Built-in display	Yes
Display diagonal	2.4 \
Display size (HxV)	240 x 320 mm
Internal memory	256 GB
Processor cores	2
Internal storage capacity	512 GB
Operating system installed	Linux
Type	Face recognition terminal
Access code reader	-
Authentication type	Biometric, Face recognition
Access chip/card reader	No
Face recognition distance	0.5 - 2 m
False Rejection Rate (FRR)	0.02 %
False Acceptance Rate (FAR)	0.01 %
International Protection (IP) code	IP65
Operating temperature (T-T)	-5 - 45 °C
Total megapixels	1 MP
RS-485 ports	1
Package weight	800 g

Weight and Dimensions

Depth	58.5 mm
Width	185 mm
Height	20 mm
Weight	300 g
