ZKTeco SpeedFace-V3L User Manual

SpeedFace-V3L User Manual
Page | 62 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Failed ID
If the verification fails, the system will send the
failed ID to the device and replace the card
number or personnel ID with the new one.
Site Code
It is similar to the device ID. The difference is that
a site code can be set manually and is repeatable
o
n a different device. The valid value ranges from
0 to 256 by default.
Pulse Width(us)
The time width represents the changes in the
quantity of electric charge with regular
high-
frequency capacitance within a specified
time.
Pulse Interval(us)
The time interval between pulses.
ID Type
Select the ID types as either User ID or card
number.
Network Diagnosis 8.7
It helps to set the network diagnosis parameters.
Tap Network Diagnosis on the Comm. Settings interface. Enter the IP address
that needs to be diagnosed and tap Start the Diagnostic Test to check
whether the network can connect to the device.

ZKTeco SpeedFace-V3L Specifications

General

Display type	LCD
Screen shape	Flat
Built-in display	Yes
Display diagonal	2.4 \
Display size (HxV)	240 x 320 mm
Internal memory	256 GB
Processor cores	2
Internal storage capacity	512 GB
Operating system installed	Linux
Type	Face recognition terminal
Access code reader	-
Authentication type	Biometric, Face recognition
Access chip/card reader	No
Face recognition distance	0.5 - 2 m
False Rejection Rate (FRR)	0.02 %
False Acceptance Rate (FAR)	0.01 %
International Protection (IP) code	IP65
Operating temperature (T-T)	-5 - 45 °C
Total megapixels	1 MP
RS-485 ports	1
Package weight	800 g

Weight and Dimensions

Depth	58.5 mm
Width	185 mm
Height	20 mm
Weight	300 g
