ZKTeco SpeedFace-V3L User Manual

SpeedFace-V3L User Manual
Page | 58 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Function Description
Function Name Description
Wiegand Format
Its value can be 26 bits, 34 bits, 36 bits, 37 bits,
and 50 bits.
Wiegand Bits
The number of bits of the Wiegand data.
Pulse Width(us)
The value of the pulse width sent by Wiegand is
100 microseconds by default, which can be
adjusted within the range of 20 to 400
microseconds.
Pulse Interval(us)
The default value is 1000 microseconds and can
be adjusted within the range of 200 to 20000
microseconds.
ID Type
Select between the User ID and card number.
Various Common Wiegand Format Description:
Wiegand Format Description
Wiegand26
ECCCCCCCCCCCCCCCCCCCCCCCCO
It consists of 26 bits of binary code. The 1
st
bit is the
even parity bit of the 2
nd
to 13
th
bits, while the 26
th
bit is
the odd parity bit of the 14
th
to 25
th
bits. The 2
nd
to 25
th
bits are the card numbers.

ZKTeco SpeedFace-V3L Specifications

General

Display type	LCD
Screen shape	Flat
Built-in display	Yes
Display diagonal	2.4 \
Display size (HxV)	240 x 320 mm
Internal memory	256 GB
Processor cores	2
Internal storage capacity	512 GB
Operating system installed	Linux
Type	Face recognition terminal
Access code reader	-
Authentication type	Biometric, Face recognition
Access chip/card reader	No
Face recognition distance	0.5 - 2 m
False Rejection Rate (FRR)	0.02 %
False Acceptance Rate (FAR)	0.01 %
International Protection (IP) code	IP65
Operating temperature (T-T)	-5 - 45 °C
Total megapixels	1 MP
RS-485 ports	1
Package weight	800 g

Weight and Dimensions

Depth	58.5 mm
Width	185 mm
Height	20 mm
Weight	300 g
