Zte ZXR10 8900 Series User Manual

Chapter10QoSConguration
ZXR10(config-if)#ipaccess-group101in
/*ApplyACL101totheinterfaceconnectingtoNetworkB*/
PolicyRoutingConfiguration
Example
WhenmultipleInternetserviceprovider(ISP)egressesexistin
anetwork,differentISPegressescanbeselectedfordifferent
groupsofusersbypolicyrouting.
AsshowninFigure29,selectdifferentegressesaccordingtothe
IPaddressesofusers.Usersinsub-network10.10.0.0/24use
theISP1egress.Usersinsub-network11.11.0.0/24usetheISP2
egress.
FIGURE29POLICYROUTINGCONFIGURATIONEXAMPLE
Congurationofswitch:
ZXR10(config)#aclstandardnumber10
ZXR10(config-std-acl)#rule1permit10.10.0.00.0.0.255
ZXR10(config-std-acl)#rule2permit11.11.0.00.0.0.255
ZXR10(config-std-acl)#exit
ZXR10(config)#redirectin10rule-id1next-hop100.1.1.1
ZXR10(config)#redirectin10rule-id2next-hop200.1.1.1
ZXR10(config)#interfacegei_1/1
ZXR10(config-if)#ipaccess-group10in
ZXR10(config-if)#exit
ZXR10(config)#interfacegei_1/2
ZXR10(config-if)#ipaccess-group10in
QoSMaintenanceand
Diagnosis
TocongureQoSmaintenanceanddiagnosis,usethefollowing
command.
CondentialandProprietaryInformationofZTECORPORATION111

Zte ZXR10 8900 Series Specifications

General

Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Ports	10/100/1000BASE-T
Layer Support	Layer 2 and Layer 3
VLAN Support	4K VLANs
QoS	8 priority queues per port
Management	CLI, Web, SNMP, RMON
Power Supply	AC or DC
Redundancy	Power supply redundancy, fan redundancy
