Chapter 77 trTCM Commands
Ethernet Switch CLI Reference Guide
294
77.3 Command Examples
This example activates trTCM on the Switch with the following settings:
• Sets the Switch to inspect the DSCP value of packets (color-aware mode).
• Enables trTCM on ports 1-5.
• Sets the Committed Information Rate (CIR) to 4000 Kbps.
• Sets the Peak Information Rate (PIR) to 4500 Kbps.
• Specifies DSCP value 7 for green packets, 22 for yellow packets and 44 for red packets.
no trtcm Disables trTCM on the port(s). C 13
trtcm cir <rate> Sets the Commit Information Rate on the
port(s).
C13
trtcm pir <rate> Sets the Peak Information Rate on the
port(s).
C13
trtcm dscp green <0-63> Specifies the DSCP value to use for
packets with low packet loss priority.
C13
trtcm dscp yellow <0-63> Specifies the DSCP value to use for
packets with medium packet loss priority.
C13
trtcm dscp red <0-63> Specifies the DSCP value to use for
packets with high packet loss priority.
C13
trtcm dscp profile <name> Specifies the DSCP profile that you want to
apply to packets on the port(s).
C13
no trtcm dscp profile Sets the Switch to apply the default DSCP
profile to packets on the port(s).
C13
Table 167 trtcm Command Summary (continued)
COMMAND DESCRIPTION M P
sysname(config)# trtcm
sysname(config)# trtcm mode color-aware
sysname(config)# interface port-channel 1-5
sysname(config-interface)# trtcm
sysname(config-interface)# trtcm cir 4000
sysname(config-interface)# trtcm pir 4500
sysname(config-interface)# trtcm dscp green 7
sysname(config-interface)# trtcm dscp yellow 22
sysname(config-interface)# trtcm dscp red 44
sysname(config-interface)# exit
sysname(config)# exit
sysname# show running-config interface port-channel 1 trtcm
Building configuration...
Current configuration:
interface port-channel 1
trtcm
trtcm cir 4000
trtcm pir 4500
trtcm dscp green 7
trtcm dscp yellow 22
trtcm dscp red 44
exit
