1. Press and hold the RESET (p. 7) button.
2. Wait until the red and green LEDs go on simultaneously on the device and the acoustic signal can be
heard (approx. 15–35 s).
3. Release the RESET button.
4. The device announces the current IP address via the speaker automatically.
NOTE
The delay after pressing RESET till the first light and sound signaling is set to 15–35 s
depending on the device model used.
Static IP Address Setting
Follow the instructions below to switch on the Static IP address mode (DHCP OFF):
1. Press and hold the RESET (p. 7) button.
2. Wait until the red and green LEDs go on simultaneously on the device and the acoustic signal can be
heard (approx. 15–35 s).
3. Wait until the red LED goes off and the acoustic signal can be heard (approx. for another 3 s).
4. Release the RESET button.
NOTE
The following network parameters will be set after restart:
• IP address: 192.168.1.100
• Network mask: 255.255.255.0
• Default gateway: 192.168.1.1
Brief Guidelines
19
