Pannoramic SCAN II 2.2.0 User’s Guide 5.6.2 Service
◦ PreScan objective protection enabled – If activated, slide area near the edges will not be
scanned to record fast preview image. If inactive, Fast Preview processing becomes
slower.
◦ Cameras – Activate BF and/or FL mode for the camera. The software automatically loads
the camera settings upon clicking the Test and apply camera settings button.
◦ Brightfield ICC Profile – Select an applicable preset color profile to be used for Brightfield
scanning from the drop-down menu. Settings according to the profile has effect on the
color set, color temperature, and gamma value of the scanned image.
Preset profiles are the following:
▪ Calibrated Linear: Color scheme is defined by calibration (Gamma value is not
included)
▪ sRGB standard: Color scheme is defined by calibration (standard Gamma value -2.2-
is applied)
▪ sRGB standard Microscope Like: Color scheme is defined by calibration (standard
Gamma value / White Point: D50)
▪ Legacy: a Color scheme calibrated for the previous software version is applied
▪ Custom: parameters are freely customizable as follows:
◦ Color Scheme
▪ Calibrated: Scheme is defined by the color calibration slide
▪ Legacy: a Color scheme calibrated for the previous software version is applied
▪ Raw: the color information of the recorded raw image is applied
◦ White Point
▪ D65: color temperature according to a standard illuminant D65 white point value is
applied (6500K / daylight)
▪ D50: color temperature according to a standard illuminant D50 white point value is
applied (5000K / horizontal daylight)
◦ Gamma
▪ Standard: a value of 2.2 is used
▪ Medium: a value of 1.8 is used
▪ Off: a value of 1.0 is used
Note:
If Lumencor SPECTRA 6 is configured as illumination unit, the
corresponding Enable Lumencor hardware trigger option is displayed
on the Filter settings form.
January 24, 2020 - Rev. 2 3DHISTECH Ltd. 123(156)
