Pannoramic SCAN II 2.2.0 User’s Guide 3.3 Inserting and Removing Slides
Warning!
Do not reach into the input/output stack movement area of the
magazine, while magazines are loaded/unloaded. The flaps (5) shown
in Figure 9 must be closed during operation!
1. Remove magazine cover, before you insert magazines.
Caution!
Replace magazine cover, when magazine is not currently used, or is
stored for a longer period. The cover prevents soiling and mechanical
damage.
2. Open the flap of the input stack (5) and put a magazine (1) into the input stack (4). The
magazine’s rack (the back side of the magazine) (2) must contact with the guide rails with its
open side towards the scanner.
3. Slide down the magazine on the input guide rails until it rests on the guide pins or
magazines.
Caution!
Make sure that the magazines are not misplaced, because it can cause
serious damages in the feeding mechanism.
Note:
The input stack can be filled with a maximum of 6 magazines in
addition to the one in the magazine loader.
