 10 78-8130-6150-0-F

C. Cleaning

Useasoftdampclothtocleantheproductandtestleadsifnecessary.

D. Service and Accessories

Informationregardingservice,accessories,orreplacementpartscanbeobtainedby

contacting3Mat1-800-426-8688.

Thisequipmentdoesnotrequireannualcalibrationormaintenance.

E. 2250 Transmitter Keypad and Connector Definitions

Trace

Output Level

Dynatel

2250

off on

T-1 T-2 T-3 T-5 T-6 T-7

[T-1] off: Turnsunitoffandperformsbatterytest.

[T-2] on: Ohm-meter / Tone: Turnstheunitonandcyclesthroughthefollowing

commandswhenpressedrepeatedly.

Ohm-meter: Measuresthecontinuityofthetraceconductor/pipeanditsfar-end

ground.Itisalsousedtomeasurethefaultresistancetoearth.

Tone: Inthetonemode,thetransmittergenerates577Hzand200kHzsignals.

[T-3] on: Trace (frequency): TurnstheunitonandplacestheunitinTracemode.

Select Frequency: PressTrace[T-3]repeatedlytocyclethroughthetransmitter’s

activefrequencies(577Hz,8kHz,33kHz,and200kHz).Theselectedfrequency

willbedisplayed[T-4].‘ALL'indicatesthatthefollowingactivefrequenciesare

transmittingsimultaneously:577Hz,8kHz,33kHz,and200kHz.

[T-4] Digital Display:

Indicator Flags: Theseflagscoincidewiththeoperationalmodeofthetransmitter.

(Fromtoplefttobottomright)Tracemode[T-3],Tonemode[T-2],Ohm-meter

[T-2],Voltage(atstartupthetransmitterchecksforforeignvoltage),andthe

OutputLevelFlag(noflag=normaloutput;flag=highoutput;flashingflag=

maximumoutput).

Digital Display: Indicatesfrequency,relativecurrent,resistance,batteryleveland

voltage(ifpresentontarget).

[T-5] Output Level: Cyclesoutputlevel;normal,highandmaximum.

Normal=NoFlag;High=Flag;Maximum=FlashingFlag(indicatedinDigital Display

[T-4])

NOTE: An external 12-volt power source is required to obtain Max Output level (12

watts for 12-watt transmitters and 5 watts for 5-watt transmitters).

3M Dynatel 2250M User Manual
