62 78-8130-6150-0-F
25. Transmitter Specifications
Item Specification
Trace Mode 577 Hz
8 kHz
33 kHz
200 kHz
Fault Mode
(2273M models only)
10/20 Hz - Fault signal
577 Hz / 33 kHz -Trace signal
Note: The fault locating limit is 2.0MΩ although the transmitter's ohmmeter
mode can display a fault resistance up to 10MΩ.
Tone Mode 577 Hz and 200 kHz pulsing at 8 Hz
Induction Mode 8 kHz (only available on 12 Watt Transmitter)
33 kHz
200 kHz
Output Power
(in Direct Connect mode)
3 Watt Transmitter Model
Normal setting: 0.5 W
High setting: 3 W @ 577 Hz, 8 kHz, 33 kHz; 1 W @ 200 kHz
5 Watt Transmitter Model
Normal setting: 0.5 W
High setting: 3 W @ 577 Hz, 8 kHz, 33 kHz; 1 W @ 200 kHz
Maximum setting: 5 W @ 577 Hz, 8 kHz, 33 kHz; 1 W @ 200 kHz
(with external DC power source)
12 Watt Transmitter Model
Normal setting: 0.5 W
High setting: 3 W @ 577 Hz, 8 kHz, 33 kHz; 1 W @ 200 kHz
Maximum setting: 12 W @ 577 Hz, 8 kHz; 10 W @ 33 kHz; 1 W @ 200 kHz
(with external DC power source)
Output Voltage (Maximum) 70 Vrms
Output Protection 240 Vrms
Weight w/batteries w/ alkaline batteries only: 5.2 lbs (2.4 kg)
w/ rechargeable battery (2200RB) and alkaline batteries (5W and 12W
transmitters only): 9.2 lbs (4.2 kg)
Battery Qty. and size For Normal and High Output Power: 6 "C" size, Alkaline (LR14)
For Maximum Output Power: Rechargeable Battery (2200RB), 12V-6AH,
Sealed Maintenance-Free Lead (Pb)-Acid Battery
(See safety information below.)
Battery Life Normal Output Power level: 50 hours typical
High Output Power level: 10 hours typical
Typical transmitter specified battery life (listed above) is increased by 40%
when using the 2200RB Rechargeable Battery (12 volt). Using the 2200RB
bypasses the alkaline batteries.
Maximum Output Power level: 4 hours typical (Maximum Output Power level
achieved using 2200RB Rechargeable Battery.)
External DC Power 9–18 V DC
Rechargeable Battery fuse 5 Amp / 32 Volt
Littelfuse MINI
®
Blade # 0297005
Cigarette Lighter Adapter
Cable fuse
4 Amp / Fast Blow 250V
