3M Dynatel 2250M User Manual

3M Dynatel 2250M

65 pages

To Next Page

To Next Page

To Previous Page

To Previous Page

Page #61 background image

Loading...

Page #61 background image

78-8130-6150-0-F 61

Item Speciﬁcation

Read Range 3M iD Markers

Near-Surface

Ball Marker

Full-Range

3 ft (0.9 m)

5 ft (1.5 m)

8 ft (2.4 m)

Detection Depth 3M Non-iD (Passive)

Markers

Near Surface

Ball Marker

Mid-Range

Full-Range

2 ft (0.6 m)

5 ft (1.5 m)

6 ft (1.8 m)

8 ft (2.4 m)

Table of Contents

Default Chapter2
- Table of Contents2
1 Safety Information6
- Intended Use6
2 About This Manual7
3 Quick Start8
- Transmitter Battery Installation8
- Receiver Battery Installation9
- Cleaning10
- Service And Accessories10
- 2250 Transmitter Keypad And Connector Definitions10
- 2273 Transmitter Keypad And Connector Definitions11
- Maximum Transmitter Output12
- Rechargeable Battery12
- 2250M Receiver Key Pad And Display Definitions13
- 2273M Receiver Key Pad And Display Definitions14
4 Menu Displays15
- Main Menu15
5 Configuring The Receiver18
- Select Depth Units18
- Setting The Receiver Clock18
- Selecting A Language18
- Enabling/Disabling Frequencies19
- Selecting External Jack Frequencies (Tone Frequencies)19
- Creating User Defined Frequencies19
- Filtering Power Frequency Interference20
- Selecting Locating Audio20
6 Buried Cables And Pipes: Transmitter Connections21
- Direct Connect Method21
- Dyna-Coupler Method23
- Induction Method24
7 Receiver Modes28
- Directional Peak (Dir Pk)28
- Directional Null (Dirnull)28
- Special Peak (Spl Pk)29
- Induction Peak (Ind Pk)30
- Expanded Mode30
- Depth And Current Estimate30
9 Locating Frequencies31
- Active Frequencies31
- Power Frequencies32
- Passive Frequencies32
- Auxiliary Frequencies32
10 Locating In Directional Peak Mode33
11 Locating Active Duct Probes (Sondes)35
- Determining Adp Depth35
12 Locating Buried Sheath Faults And Earth-Return Faults36
- Transmitter Setup36
- Pinpointing The Buried Fault37
13 Locating 3M39
- Enabling/Disabling Marker Types39
- Alert Mode39
- Single Marker Locate40
- Dual Marker Locate41
- ID Marker Depth41
- Passive Electronic Marker (Non-ID) Depth42
14 Creating/Editing Templates for 3M ™ ID Markers43
- Creating New Templates43
- Editing Templates45
15 Writing ID Markers46
- Modifying Marker Data To Be Written47
16 Reading ID Markers48
17 Reviewing Marker Read/Write History49
- Read History49
- Write History [Sk]50
18 Gps Operation50
- Activation Key50
- Serial Number And Software Version50
- Inputting The Gps Activation Key50
- Communicating With The Gps Device51
- Capturing The Gps Coordinates (Capture Mode / Mode 1)51
- Sending ID Marker Data To Gps (Capture-Transmit Mode / Mode 2)52
- Path Mapping With Gps52
19 Additional Applications53
- Aerial Faults (Toning)53
- Cable Identification55
20 Help Mode56
1000 M ™ Dynatel ™ PC Tool Kit and Locator Software Upgrades56
21 3MDynatelPcToolKitAndLocatorSoftwareUpgrades57
22 Self Test Of Receiver57
23 Product Description And Optional Accessories57
- Product Description57
- Standard Configurations58
- Optional 3M ™ Dynatel ™ Accessories59
24 Receiver Specifications60
25 Transmitter Specifications62
26 Environmental And Regulatory Specifications63
27 Rechargeable Battery Information63
