3M Dynatel 2250M User Manual

 12 78-8130-6150-0-F
NOTE: 12 Watt Output Level varies by frequency. Output is limited to 10 watts at
33 kHz and 1 watt at 200 kHz using the direct connection method.
[T-6] Output Jack: PortfordirectconnectcablesorDyna-coupler.
[T-7]External Jack: Porttoconnectcigarettelighteradaptercable,orrechargeable
battery(2200RB).Inputvoltagelevel:9-18VDC.(Onlyon5-wattand12-watt
transmitters.)
G. Maximum Transmitter Output
Anexternal12VDCsourceisrequiredfor12-WattOutput(Maxsetting)usinga12-watt
transmitteror5wattoutput(Maxsetting)usinga5-watttransmitter.Connectingthe
rechargeablebattery(2200RB)totheExternal Jack[T-7]willprovidethisexternal
source,orthecigarettelighteradaptercable(includedwith12-wattand5-watt
transmitters)canbeusedtoconnecttheDCpowerfromavehicle’sbatterysourceto
thetransmitter’sExternal Jack[T-7].
PressOutputLevel[T-5]twiceformaximumoutputmode.
Theindicatorflagwillflashwhenthetransmitterisinmaximumoutputmode.
Note: The external DC source does not charge the internal batteries.
m WARNING
To reduce the risk associated with hazardous voltage:
• Potential for electric shock exists when handling connection cables while the transmitter is
ON. Make all connections prior to powering on the unit. Turn transmitter OFF before handling
connection cables.
• Voltage greater than 240 volts will damage equipment and could cause personal injury or
death. Make all connections before turning on the transmitter. Follow standard procedures
for reducing the voltage.
• Do not change or modify this product in any way.
H. Rechargeable Battery
The3MDynatelSealedGel-CellBattery
2200RBcanbeusedasanauxiliarybatteryin
3M
™
Dynatel
™
2200SeriesTransmitters.Itplugs
intotheExternal Jack[T-7]andprovidespower
forthetransmitter.Whentherechargeablebattery
ispluggedin,normaloutput,highoutput,and
maximumoutputareavailable.Whenthe
rechargeablebatteryisconnectedtothe
transmitter,thealkalinebatteriesarebypassed.
Therechargeablebatteryisaleadacidbattery
ratedat5.4amp-hoursandisequippedwithauserreplaceablefuse(5A/32V).
Note: The internal batteries must be at least 5.4 volts. Do not remove the alkaline
batteries from the transmitter when using the rechargeable battery. Rechargeable
battery, or cigarette lighter adapter cable, is required for Maximum output level.
Rechargeable battery is shown installed in the well of the transmitter case.
