3M Dynatel 2250M User Manual

78-8130-6150-0-F 9
B. Receiver Battery Installation
Removecapfromreceiverhandle.
Installeight‘AA’sizealkalinecellbatteries(LR6)intothebatteryholderasindicatedby
thepolaritysymbols(+and–).
AttachbatteryholdertothePP3connectorinthereceiverhandle,andslideholderinto
thehandle.Replacethecap.
8 “AA” (LR6) Alkaline Batteries
1. Twist cap to open battery
compartment.
2. Slide battery compartment
out of handle.
m Caution
To reduce the risks associated with fire and explosion:
• Do not short, excessively heat, or dispose of batteries in fire.
• Install batteries with proper polarity.
• Use only Alkaline "AA" (LR 6) sized batteries.
• Do not charge batteries
• Do not use leaking batteries
To reduce the risks associated with environmental contamination:
• Dispose of batteries and electronic components in accordance with all regulations.
• Ensure batteries are installed with correct polarity.
• Always remove batteries when storing the units for long periods of time.
Thereceiverbatteriesaretestedfortwosecondseverytimetheunitisturnedon.
Thebargraphonthedisplaywillfilltotherelativebatterylevel.
TheBatteryIcon[8]ontheLocatingDisplayswillcontinuouslyindicatethebattery
level.
