3M Dynatel 2250M User Manual

78-8130-6150-0-F 15
[13] Fault Finding Direction Indicators: CorrespondstotheEarthContactFrame
(A-Frame)probe(leg)colors.
[l4] External Jack: Porttoconnectcablesfromexternaldevicessuchastheearthframe
(A-Frame),asecondDyna-Coupler,oratoningcoil.
[15]Serial Port: RS232porttoconnectthereceivertoaPCviaserialcableorUSB-to-
serialadaptercable.
[16] Earphone Jack: Willfitstandard1/8"(3.175mm)mini-jackmonoearphoneplug
(notincluded).
4. Menu Displays
A. Main Menu
WhentheMenu[6]buttonispressed,theMainMenudisplayappears.
Thefunctionappearsonthedisplayaboveeachsoftkey.
1. Write Mode: SystemusedtowriteinformationtoiDMarkers
2. Data/Template: Displaysmarkerhistoryand
templatecreation/selectiondisplays:
a. Read History –100memorylocationsfor
ReadiDMarkers
b. Write History –100memorylocationsfor
WritteniDMarkers
c. User Templates –CreateandeditiD
templatesforiDMarkers(max=32)
d. Trace Templates –Createandedit
templatesusedtoidentifypath(max=5)
