ABB ACS150 series

Actual signals and parameters
118
Parameters in the Long parameter mode
Index
Name/Selection
Description
Def
3408 SIGNAL2 PARAM
Selects the second signal to be displayed on the control panel in the Output
mode. See parameter 3401 SIGNAL1 PARAM.
104
0, 102…162
Parameter index in group 01 OPERATING DATA. For example, 102 = 0102
SPEED. If value is set to 0, no signal is selected.
If parameter 3401 SIGNAL1 PARAM, 3408 SIGNAL2 PARAM and 3415
SIGNAL3 PARAM values are all set to 0, n.A. is displayed.
3409 SIGNAL2 MIN
Defines the minimum value for the signal selected by parameter 3408
SIGNAL2 PARAM. See parameter 3402 SIGNAL1 MIN.
-
x…x
Setting range depends on parameter 3408 setting.
-
3410 SIGNAL2 MAX
Defines the maximum value for the signal selected by parameter 3408
SIGNAL2 PARAM. See parameter 3402 SIGNAL1 MIN.
-
x…x
Setting range depends on parameter 3408 SIGNAL2 PARAM setting.
-
3411 OUTPUT2 DSP
FORM
Defines the format for the displayed signal selected by parameter 3408
SIGNAL2 PARAM.
9 = DIRECT
See parameter 3404 OUTPUT1 DSP FORM.
-
3412 OUTPUT2 UNIT
Selects the unit for the displayed signal selected by parameter 3408
SIGNAL2 PARAM.
-
See parameter 3405 OUTPUT1 UNIT.
-
3413 OUTPUT2 MIN
Sets the minimum display value for the signal selected by parameter 3408
SIGNAL2 PARAM. See parameter 3402 SIGNAL1 MIN.
-
x…x
Setting range depends on parameter 3408 SIGNAL2 PARAM setting.
-
3414 OUTPUT2 MAX
Sets the maximum display value for the signal selected by parameter 3408
SIGNAL2 PARAM. See parameter 3402 SIGNAL1 MIN.
-
x…x
Setting range depends on parameter 3408 SIGNAL2 PARAM setting.
-
3415 SIGNAL3 PARAM
Selects the third signal to be displayed on the control panel in the Output
mode. See parameter 3401 SIGNAL1 PARAM.
105
0, 102…162
Parameter index in group 01 OPERATING DATA. For example, 102 = 0102
SPEED. If value is set to 0, no signal is selected.
If parameter 3401 SIGNAL1 PARAM, 3408 SIGNAL2 PARAM and 3415
SIGNAL3 PARAM values are all set to 0, n.A. is displayed.
3416 SIGNAL3 MIN
Defines the minimum value for the signal selected by parameter 3415
SIGNAL3 PARAM. See parameter 3402 SIGNAL1 MIN.
-
x…x
Setting range depends on parameter 3415 SIGNAL 3 PARAM setting.
-
3417 SIGNAL3 MAX
Defines the maximum value for the signal selected by parameter 3415
SIGNAL3 PARAM. See parameter 3402 SIGNAL1 MIN.
-
x…x
Setting range depends on parameter 3415 SIGNAL3 PARAM setting.
-
3418 OUTPUT3 DSP
FORM
Defines the format for the displayed signal selected by parameter 3415
SIGNAL3 PARAM.
9 = DIRECT
See parameter 3404 OUTPUT1 DSP FORM.
-
3419 OUTPUT3 UNIT
Selects the unit for the displayed signal selected by parameter 3415
SIGNAL3 PARAM.
-
See parameter 3405 OUTPUT1 UNIT.
-
3420 OUTPUT3 MIN
Sets the minimum display value for the signal selected by parameter 3415
SIGNAL3 PARAM. See parameter 3402 SIGNAL1 MIN.
-
x…x
Setting range depends on parameter 3415 SIGNAL3 PARAM setting.
-
