Start-up and control with I/O
• motor nominal frequency (parameter 9907 MOTOR NOM
FREQ)
Set the maximum value for external reference REF1
(parameter 1105 REF1 MAX).
Set constant speeds (drive output frequencies) 1, 2 and 3
(parameters 1202 CONST SPEED 1, 1203 CONST SPEED 2
and 1204 CONST SPEED 3).
Set the minimum value (%) corresponding to the minimum
signal for AI(1) (parameter 1301 MINIMUM AI1).
Set the maximum limit for the drive output frequency
(parameter 2008 MAXIMUM FREQ).
Select the motor stop function (parameter 2102 STOP
FUNCTION).
LOC
9907
s
PAR FWD
LOC
1105
s
PAR FWD
LOC
1202
s
PAR FWD
LOC
1203
s
PAR FWD
LOC
1204
s
PAR FWD
LOC
1301
s
PAR FWD
LOC
2008
s
PAR FWD
LOC
2102
s
PAR FWD
DIRECTION OF THE MOTOR ROTATION
Check the direction of the motor rotation.
• Turn the potentiometer fully counterclockwise.
• If the drive is in remote control (REM shown on the left),
switch to local control by pressing
LOC
.
REM
• Press to start the motor.
• Turn the potentiometer slightly clockwise until the motor
rotates.
• Check that the actual direction of the motor is the same as
indicated on the display (FWD means forward and REV
reverse).
• Press to stop the motor.
LOC
2102
s
PAR FWD
