Efficiency
Approximately 96.5% at nominal power level.
Protection classes for module
IP20 (standard)Degrees of protection
(IEC/EN 60529)
IP00 (option +0B051)
UL Type OpenEnclosure types
(UL 61800-5-1)
IIIOvervoltage category
(IEC/EN 60664-1)
IProtective class
(IEC/EN 61800-5-1)
Ambient conditions
The table shows environmental limits for the drive. The drive must be used in a heated,
indoor, controlled environment.
TransportationStorageOperation
in the protective packagein the protective packageinstalled for stationary use
--For TN and TT neutral-
grounded network systems
and IT ungrounded net-
work systems: 0 to 4000 m
(13123 ft) above sea level
Installation site altitude
Above 1000 m [3281 ft]):
see When is derating ne-
cessary (page 181)
-40…+70 °C
(-40…+158 °F)
-40…+70 °C
(-40…+158 °F)
-15…+55 °C (5…131 °F).
No frost allowed. See
When is derating neces-
sary (page 181)
Surrounding air
temperature
Max. 95%Max. 95%5…95%Relative humidity
No condensation allowed. Maximum allowed relative humidity is 60% in the pres-
ence of corrosive gases.
IEC 60721-3-2:1997IEC 60721-3-1:1997IEC/EN 60721-3-3:2002Contamination
Class 2C2Class 1C2Class 3C2Chemical gases
Class 2S2Class 1S3. (packing must
support this, otherwise
1S2)
Class 3S2. No conductive
dust allowed.
Solid particles
2Pollution degree
60…106 kPa70…106 kPa70…106 kPaAtmospheric pressure
0.6 … 1.05 atmospheres0.7 … 1.05 atmospheres0.7 … 1.05 atmospheres
Max. 3.5 mm (0.14 in)
(2…9 Hz), max. 15 m/s
2
(49 ft/s
2
) (9…200 Hz) si-
nusoidal
Max. 1 mm (0.04 in) (5 …
13.2 Hz), max. 7 m/s
2
(23 ft/s
2
) (13.2 … 100 Hz)
sinusoidal
Max. 0.1 mm (0.004 in)
(10…57 Hz), max. 10 m/s
2
(33 ft/s
2
) (57…150 Hz) si-
nusoidal
Vibration
IEC 60068-2-6:2007,
EN 60068-2-6:2008
Technical data 195
