ABB CRB 1300 - Page 43

Main dimensions of CRB 1300-7/1.4
544 575
675 90
1159
150
62,5
340
127,4
B
190
190
220
100
190
10
H7 +
0,015
0
73
73
190
K
J
J
Sidebase Cabling
0.08
R5
R5
10
H7 + 0,015
0
0,5
0,5
DETAIL K
0.08
R
101,5
118
190
190
80
170
Underbase Cabling
19
A
xx2200000727
DescriptionPos
Turning radius: R84A
Turning radius: R282B
Product manual - CRB 1300 43
3HAC083111-001 Revision: B
© Copyright 2022-2023 ABB. All rights reserved.
2 Manipulator description
2.4 Dimensions
Continued
