FSM4000 ELECTROMAGNETIC FLOWMETER | OI/FSM4000-EN REV. E 81
Submenu / parameter
Value range
Remark
AI Channel Channel setting for AI block. When setting the channel, the unit
for the channel is also copied to the AI block (from OUT_SCALE.
UNIT_INDEX).
Selection:
TB (Transducer Block) Flow Value
TB Total → F
TB Total ← R
TB Diff Total
TB Flow Value
AI Channel
TB Total → F
AI Channel
TB Total ← R
AI Channel
TB Diff Total
TOT 1 Channel
Channel setting for totalizer block.
Available only as option TB Flow Value. When setting the channel,
the volume and mass unit is also copied to UNIT_TOT (example:
m
3
/h → m
3
).
TB Flow Value
TOT 2 Channel See TOT 1.
TB Flow Value
Software Rev.
Read only Displays the communication software version.
Communication: 0
FF Address 0x15 3. FOUNDATION Fieldbus communication.
Displays the address and device ID:
000320 = manuf. code ABB, hex
0017 = Device Type Code FSM4000, hex
_FSM4000_ = Device name
12345 = serial number of device, 5-digit
Dev-ID
0003200017_FSM40
00_12345
