412 Parameters
0…3,600,000 ms Time
STO.21 STO output Sets the digital output that indicates the
status of the STO function in the drive.
Active when the STO circuit in the drive is
open.
Note: In a cascade connection, this
indicates the activity of the STO function of
the FSO module.
None
None No output connected
DO X113:7 & X114:7 Redundant output X113:7 & X114:7
DO X113:8 & X114:8 Redundant output X113:8 & X114:8
DO X113:9 & X114:9 Redundant output X113:9 & X114:9
DO X113:7 Single output X113:7
DO X113:8 Single output X113:8
DO X113:9 Single output X113:9
DO X114:7 Single output X114:7
DO X114:8 Single output X114:8
DO X114:9 Single output X114:9
STO.22 STO completed
output
Sets the digital output that indicates the
completion of the STO function. See the
diagrams in section Safe torque off (STO) on
page 67.
None
None No output connected
DO X113:7 & X114:7 Redundant output X113:7 & X114:7
DO X113:8 & X114:8 Redundant output X113:8 & X114:8
DO X113:9 & X114:9 Redundant output X113:9 & X114:9
DO X113:7 Single output X113:7
DO X113:8 Single output X113:8
DO X113:9 Single output X113:9
DO X114:7 Single output X114:7
DO X114:8 Single output X114:8
DO X114:9 Single output X114:9
SBC
Parameters for the SBC function
SBC.01 SBC version Shows the version of the SBC function. Version 1
Version 1 Version 1.
SBC.11 STO SBC usage Sets how the mechanical brake (SBC) is
used together with the STO function.
Note: This parameter is used also in the
SSE function when it is configured as
Immediate STO (parameter SSE.13 SSE
function = Immediate STO).
Delayed
brake
None No brake
Index Name/Value Description Factory
default
