434 Parameters
DO X114:9 Single output X114:9
SDI.31 SDI negative input A Sets the digital input connected to the SDI
primary input for negative rotation.
None
None No input connected
DI X113:1 & X114:1 Redundant input X113:1 & X114:1
DI X113:2 & X114:2 Redundant input X113:2 & X114:2
DI X113:3 & X114:3 Redundant input X113:3 & X114:3
DI X113:4 & X114:4 Redundant input X113:4 & X114:4
DI X113:1 Single input X113:1
DI X113:2 Single input X113:2
DI X113:3 Single input X113:3
DI X113:4 Single input X113:4
DI X114:1 Single input X114:1
DI X114:2 Single input X114:2
DI X114:3 Single input X114:3
DI X114:4 Single input X114:4
Always on The SDI negative function is always on.
SDI.32 SDI negative input B Sets the digital input connected to the SDI
secondary input for negative rotation.
The secondary output is mostly used for
cascade connection. See parameters
SAFEIO.12 Cascade A and SAFEIO.13
Cascade B.
None
None No input connected
DI X113:1 & X114:1 Redundant input X113:1 & X114:1
DI X113:2 & X114:2 Redundant input X113:2 & X114:2
DI X113:3 & X114:3 Redundant input X113:3 & X114:3
DI X113:4 & X114:4 Redundant input X113:4 & X114:4
DI X113:1 Single input X113:1
DI X113:2 Single input X113:2
DI X113:3 Single input X113:3
DI X113:4 Single input X113:4
DI X114:1 Single input X114:1
DI X114:2 Single input X114:2
DI X114:3 Single input X114:3
DI X114:4 Single input X114:4
Always on The SDI negative function is always on.
SDI.33 SDI negative output
A
Sets the digital output connected to the SDI
negative primary output. Active when the
motor rotates in the correct (negative)
direction.
None
None No output connected
Index Name/Value Description Factory
default
