Parameters 445
50…59,000 ms Time
SAFEIO.33 DI X113:1 diag pulse
on/off
Sets the diagnostic pulse of digital input
X113:1 on or off.
On
Off Diagnostic pulse off
On Diagnostic pulse on
SAFEIO.34 DI X113:2 diag pulse
on/off
Sets the diagnostic pulse of digital input
X113:2 on or off.
On
Off Diagnostic pulse off
On Diagnostic pulse on
SAFEIO.35 DI X113:3 diag pulse
on/off
Sets the diagnostic pulse of digital input
X113:3 on or off.
On
Off Diagnostic pulse off
On Diagnostic pulse on
SAFEIO.36 DI X113:4 diag pulse
on/off
Sets the diagnostic pulse of digital input
X113:4 on or off
On
Off Diagnostic pulse off
On Diagnostic pulse on
SAFEIO.37 DI X114:1 diag pulse
on/off
Sets the diagnostic pulse of digital input
X114:1 on or off.
On
Off Diagnostic pulse off
On Diagnostic pulse on
SAFEIO.38 DI X114:2 diag pulse
on/off
Sets the diagnostic pulse of digital input
X114:2 on or off.
On
Off Diagnostic pulse off
On Diagnostic pulse on
SAFEIO.39 DI X114:3 diag pulse
on/off
Sets the diagnostic pulse of digital input
X114:3 on or off
On
Off Diagnostic pulse off
On Diagnostic pulse on
SAFEIO.40 DI X114:4 diag pulse
on/off
Sets the diagnostic pulse of digital input
X114:4 on or off
On
Off Diagnostic pulse off
On Diagnostic pulse on
SAFEIO.51 DO diagnostic pulse
length
Sets the length of the diagnostic pulse for
digital outputs.
1ms
0.5 ms Length of the diagnostic pulse is 0.5 ms.
1 ms Length of the diagnostic pulse is 1 ms.
2 ms Length of the diagnostic pulse is 2 ms.
SAFEIO.52 DO diagnostic pulse
period
Sets the time during which the FSO module
must receive at least one whole diagnostic
pulse.
10,000 ms
50…59,000 ms Time
Index Name/Value Description Factory
default
