Parameters 447
Active high Active state of the output is high voltage.
SAFEIO.76 DO X114:9 logic
state
Sets the logic state of digital output X114:9. Active low
Active low Active state of the output is low voltage.
Active high Active state of the output is high voltage.
41
SBUSGEN
General parameters for safety fieldbusses
SBUSGEN.
01
SBUS activity and
version
Activates or deactivates the safety fieldbus. Disabled
Disabled Deactivates the safety fieldbus.
Version 1 Activates version 1 of the safety fieldbus.
SBUSGEN.
06
Safety fieldbus
speed scaling
Sets the rpm value that corresponds to
20000 for safety fieldbus communication.
1500.0 rpm
0.10…30000.0
SBUSGEN.
07
Safety fieldbus
position scaling
Sets the scaling value for the shaft rotation
(base unit 1/1000 grad). If this parameter is
set to 1000, value 400 in the safety fieldbus
equals to one full shaft revolution.
Note: This parameter is relevant only when
an encoder is used.
1.0
0.01…30000.0
SBUSGEN.10 STO indication
passivation
Sets the type of the event that the FSO
module generates when the FSO module is
passivated due to safety fieldbus problems.
Fault
None No event generated
Fault Fault generated
Warning Warning generated
Event Pure event generated
41
PROFIsafe
Parameters for PROFIsafe
PROFIsafe.11 PROFIsafe
F_Dest_Add
Sets the PROFIsafe destination address for
FSO which is used in the safety
communication network.
Note: This address must be the same as is
set in the F-Parameters for the PROFIsafe
module properties (F_Dest_Add). For more
information, see section Configuring the
safety PLC on page 231.
1
1…65534
PROFIsafe.
12
PROFIsafe telegram
type
Shows the PROFIsafe telegram type. 0x221
0x221 PROFIsafe telegram 0x221 (545).
Corresponds to profile ABB_PS1 in the GSD
file. See section Downloading the GSD file
on page 231.
Index Name/Value Description Factory
default
