11.1 Application, special tools
Special tools (90160)
Fig.90: Special tools
Part number Description Quantity
90160 Special tools, complete 1
90161 Bag 1
90165 Spanner holder 1
90166 Spanner holder 1
Table61: Special tools (90160)
Customer tool (not included in the ABB Turbo Systems scope of delivery)
Fig.91: Client tool
Position Description Quantity
01 Collection tub 500x400x30mm 1
02 Torque spanner 40-200 Nm with
plug connection for holding inser-
tion tools 14x18 mm
1
Table62: Client tool
