ABB HVC User Manual

HVC 450 kW E-Bus Charger Installation Guide
Revision: 1.2 COMPANY CONFIDENTIAL
Date released: 16-08-2018 Page 112 of 128
8. Technical Specification
8.1. Electrical specification complete system
Input
Supply voltage
3-phase, 480 V AC: GND, L1, L2, L3
Input voltage range
480 V AC ± 10%
Input frequency range
60 Hz ± 1%
Maximum power dissipation
520 kVA
Power factor (cos ᵠ)
≥ 0.95
Standby power consumption
< 180 W
Efficiency
93 % - 95 % (dependent on load)
Nominal input current
576 A AC
Maximum nominal input current
660 A AC
Maximum peak input current
771 A AC
Earth Leakage Current
DC 1.0 mA DC
AC 300 mA (GFCI integrated in HVC150(S))
AC 30 mA (GFCI integrated in ACS Control
Module)
Short Circuit Capacity
25 kA
AC power connection
240 mm
2
= 500 MCM (max)
DC output
Maximum output power
450 kW
Output voltage range
150 – 850 V DC
Maximum output current
0 – 600 A DC
8.2. Mechanical data
Mechanical specification Power Cabinet
Dimensions (H x W x D)
82.36 x 46.06 x 30.32 Inch (Including swivel eye
bolts)
Weight
2954.19 lb
Volume
114114.40 in
3
Dimensions including packaging (H x W x D)
88.58 x 47.24 x 31.50 Inch
Weight including packing
3086.47 lb
Weight concrete foundation
2866.00 lb
Mechanical impact protection
IK10
Housing
Stainless steel 430
Mechanical specification ACS Control Module
Dimensions (H x W x D)
33.13 x 24.04 x 8.66 Inch
Weight
108.03 lb
Volume
6102.37 in
3
Dimensions including packaging (H x W x D)
34.25 x 32.28 x 16.54 Inch
Weight including packing
123.46 lb
Mechanical impact protection
IK10
Housing
Stainless steel 304 (316 for close to the sea)
Mechanical specification ABB Pole
Dimensions footprint (W x D)
40.95 x 11.81 Inch
Height
206.30 Inch
Outreach
183.86 Inch
Weight
3761.09 lb (including ACS Control Module)
Dimensions packaging for plates (H x W x D)
63.39 x 46.06 x 121.06 Inch
Weight packing for plates
1984.16 lb (including plates)
Total weight concrete foundation
20172.30 lb (=9920.80 lb + 2 x 5125.75 lb)
Mechanical impact protection
IK10
Housing
Aluminum

ABB HVC Specifications

General

Brand	ABB
Model	HVC
Category	Battery Charger
Language	English
