ABB HVC User Manual

HVC 450 kW E-Bus Charger Installation Guide
Revision: 1.2 COMPANY CONFIDENTIAL
Date released: 16-08-2018 Page 49 of 128
Data cables
Functional description
Interlock cable
CAN cable
Number of (twisted) pairs
2 x 2
1 x 2
Cross section
18 – 14 AWG
20 – 18 AWG
Min – Max external diameter to fit
through gland
0.20 – 0.39 Inch
inapplicable
Shielding
Yes (tinned copper braid)
Yes (tinned copper braid)
Conductor
Fine strand copper wire
Fine strand copper wire
Insulation
PVC or other material that can be
used outdoor and are UV-
protected
PVC or other material that can be
used outdoor and are UV-
protected
Characteristic impedance
120 Ω ± 10%
120 Ω ± 10%
Test Voltage
1.5 kV
1.5 kV
Ambient Temperature range
-40ºC to 80ºC
-40ºC to 80ºC
Core identification
Acc. to DIN 47100
Acc. to DIN 47100
 Important: all cables must be resistant to being placed in the ground, submerged in
conduit.
 All cables must have and isolation that are self-extinguishing and flame retardant
according to UL VW-1, CSA FT1.
 All cables must be must meet the UL and the RoHS compliance.
Cables between ACS Control Module and Pantograph
These cables normally integrated within the ABB pole, however, these cables needed if the
charge system is ordered without ABB pole.
Power cables
Functional description
DC Power cable
PE cable
DC- OVP Sensing cable
Number of cores
1
1
1
Cross section
350 – 600 MCM
2 AWG
8 AWG
Min – Max external
diameter to fit through
gland
1.06 – 1.38 Inch
0.51 – 0.83 Inch
0.51 – 0.83 Inch
Shielding
No
No
No
Conductor
Tinned copper or
aluminum conductor, fine
wire
stranded acc. to VDE
0295 cl.5/IEC Cl.5
Fine strand copper wire
acc. to VDE 0295 Cl. 5/
IEC 60228 Cl. 5
Bare copper, fine wired,
bunch stranded acc. to
VDE 0295 Cl.5/IEC Cl.5
Insulation
Special rubber or PVC
(outdoor use, UV-
protected, oil resistant)
Special PVC (outdoor
use, UV-protected, oil
resistant)
Special rubber or PVC
(outdoor use, UV-
protected, oil resistant)
Nominal Voltage Uo/U
600/1000 Vac
900/1500 Vdc
600 Vac
1.8/3 kVac
Test Voltage
6 kV
4 kV
6 kV
Ambient Temperature
range
-40ºC to 105ºC,
permissible conductor
operating
temperature +90°C
-40ºC to 105ºC
-40ºC to 105ºC
Core identification
gn/ye or gn
