NoteAction
WARNING
Handling gearbox oil involves several safety
risks. Before proceeding, please read the
safety information in the section Safety risks
during work with gearbox lubricants (oil or
grease) on page 36.
2
Shown in Location of oil plugs on
page 126.
Remove the oil plug, filling. (Ventilation hole
plug should also be removed.)
3
Tightening torque: 24 Nm.
Art.no. and total amount are specified
in Required equipment on page 127.
Refill gearbox with lubricating oil.
The amount of oil to be filled depends on the
amount that was previously drained.
4
Shown in Location of oil plugs on
page 126.
Refit oil plug,filling and ventilation hole plug.5
Tightening torque: 25 Nm.
Product manual - IRB 460 129
3HAC039842-001 Revision: P
© Copyright 2012-2018 ABB. All rights reserved.
3 Maintenance
3.4.3 Changing oil, gearbox axes 2 and 3
Continued
