EBTH TEMPERATURE TRANSMITTER
CREATE/MODIFY CONFIGURATION
B - 2
Key Display Comments
Select NEW to create a new configuration. To mo d i f y
an existing configuration, select MODIFY. The
screen sequence is the same, however, the MODIFY
screens will appear with the values and cursor posi-
tions as originally configured.
Select HART.
Select EBTH.
Enter a name for the configuration ID tag using up to
eight ASCII characters. To select a character, press
the key that has the desired character. Continue to
press the key until the desired character appears.
Use the right arrow key to move to the next charac-
ter. Use the left arrow key to go back to the previous
character.
For this example select ANALOG.
Type a descriptive message using up to 32 charac-
ters. This field can be used to note anything of impor-
tance to the device or installation.
To select a character, press the key that has the
desired character. Continue to press the key until the
desired character appears. Use the right arrow key to
move to the next character. Use the left arrow key to
go back to the previous character.
Type a descriptor string using up to 16 characters.
This field can be used for notations about the device
or process.
To select a character, press the key that has the
desired character. Continue to press the key until the
desired character appears. Use the right arrow key to
move to the next character. Use the left arrow key to
go back to the previous character.
CONFIG
CONFIGURATION
→ NEW
MODIFY
ERASE
ENTER
DEVICE TYPE
ABB FSK
→ HART
ENTER
TRANSMITTER TYPE
PTH → EBTH
TB82 pH TB82 ORP
TB82 pION TB82 CONC
ENTER
STT04 CONFIGURATION
[]
←PREVIOUS NEXT→
ENTER
SELECT MODE:
→ ANALOG
DIGITAL
ENTER
MESSAGE:
←PREVIOUS NEXT→
ENTER
DESCRIPTOR:
←PREVIOUS NEXT→
