3.10.2 General description of the buttons
Button Name Description
CCS
To select the CCS connector
CHAdeMo
To select the CHAdeMo connector
Language To change the language on the
touchscreen. The button shows the code
of the selected language.
Start
To start the charge session
Stop
To stop the charge session
3.11 Local Service Portal
The Local Service Portal is a service tool available on the EVSE for these purposes:
• provide information about the EVSE
• allow for the configuration of the key parameters during commissioning
• enable diagnostic on site
For the operation procedures, refer to section 6.8.
Description
36 9AKK108466A3703-EN | 001
