10.12 Dimensions
10.12.1 General dimensions
Parameter Specification
[mm] [ft-in]
Width of the cabinet (X-dimension) 565 1' 10"
with cable management system 580 1' 11"
Depth of the cabinet (Y-dimension) 880 2' 10"
with cable management system 890 2' 11"
Height of the cabinet (Z-dimension) 1900 6' 3"
Maximum opening size of the cable inlet 206 x 30 8.11" x 1.2"
Parameter Specification
[m] [ft]
Length of the charge cable (air-cooled)
1
4 13
6 20
8* 26
* The maximum cable length supported by the ABB cable retraction system is 6
m (20 ft). If the EVSE is equipped with a cable longer than 8 m (26 ft) the EVSE
is not compliant with NEC 625.17. An external cable management system must be
installed to comply with the standard.
10.12.2 Packaged product
The EVSE is mounted on a standard size wooden pallet (Europallet) and protected
to prevent damages during transport.
• A road packaged EVSE is protected with a plastic wrapping.
• A wooden crate packaged EVSE is protected with a plastic wrapping and
enclosed inside a wooden crate.
Parameter
Specification
[mm] [imperial]
Width 1200 3’ 11”
Depth 800 2’ 7”
Heigth 2100 6’ 10”
Mass of a road packaged EVSE EVSE weight + 35
kg
EVSE weight + 77 lb
Mass of a wooden crate packaged EVSE EVSE weight + 75
kg
EVSE weight + 165
lb
Maximum tipping angle 15° 15°
1
Different lengths possible
