ABB Terra 124 - Harmonics on the Grid; Terra 184

Parameter Specification
Ambient temperature Power Output [%] De-rating [%]
[°C] [°F]
-35 ... + 35 -31 … +95 100 0
+ 36 … + 40 +96 …+104 100 0
+ 41 … + 45 +105 …+113 93 7
+ 46 … + 50 +114 …+122 80 20
+ 51 … + 55 +123 …+131 67 33
The output power of the EVSE can be limited by the temperature of the charge
connector. This limitation can be caused by the connector model and rating, the EV
socket rating and the ambient conditions.
10.15 Harmonics on the grid
10.15.1 Terra 184
Working
point
Electric
load
V
thd
(L1/L2/L3) I
thd
(L1/L2/L3)
900 V /
200 A
100 % 0.669 % 0.638 % 0.698 % 3017 % 3070 % 2984 %
Order Phase L1 Phase L2 Phase L3
IRMS HDF IRMS HDF IRMS HDF
[A] [%] [A] [%] [A] [%]
1
225.10 100.00 225.25 100.00 225.04 100.00
2 0.17 0.07 0.66 0.30 0.64 0.29
3 0.57 0.25 0.52 0.23 1.08 0.48
4 0.42 0.19 0.17 0.08 0.34 0.15
5 6.06 2.69 6.21 2.76 5.76 2.56
6 0.23 0.10 0.25 0.11 0.53 0.24
7 2.07 0.92 1.93 0.86 2.08 0.93
8 0.35 0.15 0.18 0.08 0.21 0.09
9 0.19 0.08 0.14 0.06 0.13 0.06
10 0.05 0.02 0.04 0.02 0.09 0.04
11 0.36 0.16 0.31 0.14 0.42 0.19
12 0.26 0.11 0.16 0.07 0.31 0.14
13 0.63 0.28 0.75 0.33 0.57 0.26
14 0.26 0.11 0.15 0.07 0.24 0.11
15 0.01 0.01 0.17 0.08 0.16 0.07
16 0.20 0.09 0.39 0.18 0.30 0.13
17 0.85 0.38 0.78 0.35 0.76 0.34
18 0.25 0.11 0.27 0.12 0.47 0.21
