ABB Terra 124 - Terra 124; Terra 184; DC output specifications; General specifications

Note: Power limiting is possible via software configuration.
10.16.5 Terra 124
Parameter Specification
Maximum rated input current 153 A
Recommended input circuit breaker 200 A
Maximum power dissipation 127.2 kVA
Short circuit current rating 65 kA
Maximum size of the input wire 500 kcmil
Note: Power limiting is possible via software configuration.
10.16.6 Terra 184
Parameter
Specification
Maximum rated input current 230 A
Recommended input circuit breaker 300 A
Maximum power dissipation 191.3 kVA
Short circuit current rating 65 kA
Maximum size of the input wire 500 kcmil
Note: Power limiting is possible via software configuration.
10.17 DC output specifications
10.17.1 General specifications
Parameter
Specification
DC output voltage range, CCS 200-920 V DC
DC output voltage range, CHAdeMO 150-500 V DC
(In Japan 150-450 V DC)
Minimum DC output current 15 A
Connection standard CHAdeMO 1.2
CCS (IEC 61851-23:2014 , IEC62196-1:
2014, IEC 62196-3: 2014)
Technical data
96 9AKK108466A3703-EN | 001
