10 Technical data
10.1 EVSE type
The EVSE type is a code that has 7 parts
Part description Value Meaning of the value
Brand Terra -
Model and design genera-
tion
94 Fourth generation charger, 90 kW DC
output: 3 power modules installed
104 Fourth generation charger, 100 kW DC
output: 4 power modules installed
124 Fourth generation charger, 120 kW DC
output: 4 power modules installed
184 Fourth generation charger, 180 kW DC
output: 6 power modules installed
Certification CE IEC compliant
UL UL compliant
EV charger cable connec-
tion
C (C1) CCS-1 connector
C (C2) CCS-2 connector
J CHAdeMO
EV charge cable length 4 4 m (13 ft)
6 6 m (20 ft)
Connector type A Air cooled EV charge cable(s)
Power rating 1 Max 125/150 A current
2 Max 200 A current
4 Max 400 A current
Example
Terra 184 UL C 6A4:
• Brand = Terra
• 184 = Fourth generation charger, 180 kW DC output
• UL = Local certification for North America
• C = CCS connector
• 6 = The length of the EV charge cable(s) is 6 m (20 ft)
• A = Air cooled EV charge cable(s)
• 4 = Max 400 A current
10.2 General specifications
Parameter
Specification
Compliance and safety UL 2202:2009 R2.18
CSA STD C22.2 No 107.1-16
Technical data
9AKK108466A3703-EN | 001 73
