5 Installation
5.1 General installation procedure
Preliminary requirements
• All required permits to
obey the local rules are
granted.
• The AC input cable is
available.
• Tools for installation. Refer
to section 10.5.
•
Installation engineer
• There is no voltage on
the AC input cable during
the complete installation
procedure.
Procedure
1. Prepare for installation. Do these steps:
a. Prepare the site. Refer to section 5.2.1.
b. Unpack the EVSE. Refer to section 4.2.1.
c. Move the cabinet to the correct location. Refer to section 4.3.
2. If a lower installation of the EVSE is required, for wheelchair accessibility,
remove the base. Refer to section 10.10.4.
3. Do the mechanical installation. Refer to section 5.5.1.
4. Do the electrical installation. Refer to section 5.6.1.
5. If it is necessary, install these optional elements:
• Tilt sensors. Refer to section 5.7.
• Cable management system. Refer to section 5.8.
6. Prepare for commissioning. Refer to section 5.9.
5.2 Site preparation
5.2.1 Prepare the site
Preliminary requirements
• Installation engineer
Installation
42 9AKK108466A3703-EN | 001
