3.3.2 Electromagnetic immunity
In accordance with the IEC 60601-1-2 Ed4 standard, X-MIND prime is suitable for use in
the electromagnetic environment specified below.
The customer or user of the system must ensure that it is used in the said environment.
Immunity
test
IEC 60601-1-2
test level
Compliance
level
Electromagnetic
environment
Electrostatic
discharge (ESD)
IEC 61000-4-2
8 kV contact
2/4/8/15 kV air
IEC 60601-1-
2
Test level
Floors should be wood,
concrete or ceramic tile. If
floors are covered with
synthetic material, the relative
humidity should be at least
30%
Radiated
electromagnetic
field
IEC 61000-4-3
3 V/m
80 MHz to 2.7 GHz
IEC 60601-1-
2
Test level
Portable and mobile RF
communications equipment
should be used no closer to
any part of X-MIND prime
including cables.
Minimum distance 30 cm
Electrical fast
transient/burst
IEC 61000-4-4
2 kV for power
supply lines
1 kV for
input/output lines >
3 m
IEC 60601-1-
2
Test level
Mains power quality should be
that of a typical commercial or
hospital environment
Surge
IEC 61000-4-5
0.5/1 kV differential
mode
0.5/1/2 kV common
mode
IEC 60601-1-
2
Test level
Mains power quality should be
that of a typical commercial or
hospital environment
Conducted
disturbances
induced by RF
fields
IEC 61000-4-6
3 V
150 kHz to 80 MHz
6 V
ISM frequencies
IEC 60601-1-
2
Test level
Portable and mobile RF
communications equipment
should be used no closer to
any part of X-MIND prime,
including cables.
Minimum distance 30 cm
Voltage dips,
short
interruptions and
voltage
variations on
power supply
input lines
IEC 61000-4-11
10 ms – 0 % a 0°,
45°, 90°, 135°,
180°, 225°, 270°,
315°
20 ms – 0% a 0°
500 ms – 70% a 0°
5 s – 0%
IEC 60601-1-
2
Test level
Mains power quality should be
that of a typical commercial or
hospital environment. If the
user of X-MIND prime
requires continued operation
during power mains
interruptions, it is
recommended that X-MIND
prime be powered from an
uninterruptible power supply
or a battery
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
30 A/m
IEC 60601-1-
2
Test level
Power frequency magnetic
fields should be at levels
characteristics of a typical
location in a typical
commercial or hospital
environment
