7.1 Quality check tools
The following tools are required to perform the quality check:
•
Support plate (P/N 6195170100): used to check laser alignment and to hold the
centering tool (P/N 6195170200)
•
Centering tool (P/N 6195170200): used to check image quality
•
A.I.S. software: used to acquire image and perform measurements
•
SyMage software: used to perform measurements on the image. The SyMage.exe
is located at C:\Program Files (x86)\Acteon Imaging\Panoramic X-Mind
prime\SyMage
•
PhD_Test software: used to perform exposure without arm rotation. The
PhD_Test.exe is located at C:\Program Files (x86)\Acteon Imaging\Panoramic X-
Mind prime
•
kV meter (NOT provided with the equipment): used to measure exposure
parameters.
Except kV meter, all these tools are provided with the unit.
