9. ERROR MESSAGES
The error messages are divided into different areas that can be distinguished by the error
number; the following table contains the different errors with meanings.
Main MCU board
Code
Error description
000 / 001
Internal MCU error
400 ÷ 411
MCU – DSPU communication fault (CAN Bus)
MCU EEPROM configuration
Code
Error description
100 / 101
Configuration area parameter doesn't match the expected one
102
Wrong version number in configuration area
103 / 104
Timeout error occurred during an EEPROM erase/write operation
Rotation Motor
Code
Error description
200
Zero position optical sensor of rotation axis always activated
201
Zero position optical sensor never activated
202 / 203
Zero position optical sensor of rotation still active after exiting from zero
sensor
204
Unexpected activation of rotation optical sensor
205
Timeout on rotation
Y translation motor
Code
Error description
240
Zero position micro Y always active
241
Zero position micro Y never active
243
Timeout on Y axes
Disk collimator
Code
Error description
260
Collimator timeout on zero positioning
Hardware keyboard (U.I.C.)
Code
Error description
270 / 271
Hardware key fault
