8. GENERAL INSTRUCTIONS FOR USE
8.1 Switching the device ON and OFF
Warning
The unit must be connected to a differential magneto-thermal switch to divide
the unit from the supply. This switch must comply the electrical regulations in
force in the country of installation.
Minimum requirements at 230V: working voltage 250V, current 10A and
differential current 30 mA.
Minimum requirements at 115V: working voltage 150V, current 25A and
differential current 30 mA.
Press the power switch located on the upper part of the equipment on the operator side
to position "1".
This will start the "CHECK" function, which is indicated by LEDs lighting up on the
equipment keyboard.
When the "CHECK" function is complete, the green LED (3 - Figure 10) on the equipment
keyboard starts blinking.
To carry out an exam follow the instruction from paragraph 8.6.
To switch OFF the unit press the power switch located on the upper part of the equipment
on the operator side to position "0".
The LEDs will go off.
8.1.1 Emergency button
The equipment has a red emergency button located on the upper part of the unit, near
the power switch.
The emergency button only stops the vertical column movement.
In case of an emergency column situation, press the emergency button to stop the
movement.
If columns don't move, check that the emergency button is not pressed; rotate the button
to release it.
