11.2 Patient positioning errors
11.2.1 Turned head
Figure 34
Problem
The patient's head is turned to one side (left or right) in
the mid-sagittal plane.
Effects
Condyles are different in size.
The ramous on one side is much wider that the other
one.
Asymmetric spine compensation.
