User Manual – Technical characteristics
USER MANUAL • X-MIND prime • (19) • 01/2020 • NXMPEN010C
23
Exposure times
Panoramic exam (PAN)
14.4 s Adult / 13.3 s Child
Half-panoramic exam
7.8 s Adult / 7.3 s Child
Ortho Rad panoramic exam
11.9 s Adult / Child
Low dose panoramic exam
11.9 s Adult / 10.8 s Child
Frontal dentition
4.4 s Adult / Child
Bitewing Right, Bitewing Left
3.1 s Adult / Child
Bitewing Right & Left
6.2 s Adult / Child
TMJ mouth closed/open
4.8 s per image for left and right joint in
open and closed condition
Sinus P/A projection
9.4 s
Exposure time accuracy
± 5 % or ± 20ms whichever is greater
Exam modes
Exam selection
• Automatic selection for Adult and Child,
3 Sizes
• 3 biting modes (Panoramic exam)
• Manual selection
Panoramic exam
• Standard panoramic
• Half panoramic L/R
• Ortho Rad panoramic
• Low dose panoramic
• Frontal dentition
• Bitewing L/R
• Bitewing L and R
TMJ (Temporal Mandibular Joint) exam
TMJ open and closed mouth
Sinus exam
Sinus P/A projection
