On the basis of the selections made, the display will show the kV and mA settings, as in
the tables:
Exposure values in PAN mode
Adult Patient
(14.4 seconds)
Child Patient
(13.3 seconds)
kV
mA
kV
mA
Small
64
5.6
64
4.5
Medium
66
5.6
66
4.5
Large
68
5.6
68
4.5
Exposure values in Bitewing mode
Adult Patient
(3.1 / 6.2 seconds)
Child Patient
(3.1 / 6.2 seconds)
kV
mA
kV
mA
Small
64
5.6
64
4.5
Medium
66
5.6
64
4.5
Large
68
5.6
68
4.5
Note
The exam parameters set as the default are values to be taken as the starting
point. Users can optimise the parameters according to their needs.
Once the settings have been completed, the chin support must be placed in position.
