USER MANUAL • X-MIND prime • (19) • 01/2020 • NXMPEN010C
Note
The exam parameters set as the default are values to be taken as the starting
point. Users can optimise the parameters according to their needs.
Once the settings have been completed, the chin support must be placed in position.
Note
X-MIND prime is based on a standard dentition and ascending rami shape. This
shape, based on statistical data, establishes a standard shape for the
dentomaxillofacial complex, also defining the position and the direction of the
condyles. Patient anatomy can differ significantly from the statistical model;
based on experience and competence, the user has to judge this variation.
IN ANY CASE, RADIOGRAPHY IMAGES CANNOT BE USED TO PERFORM
CALCULATIONS OF DISTANCES, ANGLES ETC. ON THE IMAGE.
Warning
The measurement of lengths on digital images depends on the specific length
calibration of the programme used. It is therefore very important to check the
length calibration of the programme. With SINUS exams, to obtain the
measurement of the anatomical part, taking into consideration the enlargement
factor, the length calibration factor is 100 pixels = 7.9 mm (in the centre of the
focus layer).
