Acteon X-MIND prime - Page 86

User Manual – General instructions for use
USER MANUAL • X-MIND prime • (19) • 01/2020 • NXMPEN010C
80
1. Ask the patient to remove all metallic objects located in the area to be X-rayed
(necklaces, earrings, glasses, hairpins, removable dental prosthesis, etc.). Ensure
that there are no thick garments in the area to be X-rayed (coats, jackets, ties, etc.).
2. Ask the patient to put on the protective apron, or something similar, making sure it
does not interfere with the trajectory of the X-ray beams.
3. Place the patient in a standing position at the SINUS chin support. With the "Column
movement" keys (1/2 - Figure 10), raise/lower the column until the chin support is
aligned with the patient's chin.
Warning
During the patient positioning, make sure the equipment cannot collide with any
object in the room.
4. Position the patient with the temple clasps ensuring that the chin is positioned on
the dedicated support; ask the patient to place his hands on the front supports.
5. Instruct the patient to close his eyes.
6. Press the "Luminous centring devices" key (2 - Figure 10). Two laser beams will light
up the sagittal medial plane line and the horizontal line for the Frankfurt plane
reference (the plane that identifies a line that ideally links the ear hole - the auditory
meatus - with the lower part of the orbital fossa). Position the patient's head in such
a way as to ensure that the first two luminous beams fall in correspondence with
respective anatomical references (Figure 24).
The luminous beam of the Frankfurt plane can be adjusted according to the patient's
height; this can be adjusted by means of the laser knob (4 - Figure 24).
Note
The laser centring devices remain on for approximately 2 minute; shutdown can
be anticipated by pressing the "Luminous centring device" key (2 - Figure 10)
or, with alignment complete, by pressing the "Patient entrance" key (6 - Figure
10) to begin preparation for exposure.
7. Close the temple clasps; this will help the patient to stay in a correct position. Check
that, during this phase, the patient has not changed position.
8. Press the "Patient Entrance" (6 - Figure 10) key to confirm the parameters. The
luminous centring devices switch off and the rotating arm goes to the exam start
position. Once alignment has been completed, the green LED "Ready for X-ray" (3
- Figure 10) lights up to indicate that pressing the X-ray button once more will start
the radiation phase.
9. Ask the patient to: close his mouth, keep perfectly still and not look at the rotating
arm during movement.
Note
With paediatric patient it is recommended to have a greater attention in taking
exams. Useful information and a specific checklist can be found at the Image
Gently website (www.imagegently.org).
In general with child and adolescent patients, before taking the exposure it is
suggested to run the exam in test mode in such a way to show the young
patient how the unit works and make them feel comfortable.
