5.3.3 Setting GPIB
5-10
5.3.3 Setting GPIB
These settings are enabled when the GPIB interface is selected.
• Setting the address
Operation Character display area
1. 6146
Press MENU and select ..7..I/F with , or .
MENU
..7.. I/F
6156
Press MENU and select ..8..I/F with , or .
MENU
..8.. I/F
2.
Enter the Select level with .
(Currently set I/F)
I/F
USB BUS
(If the GPIB interface is currently set, start from Step 6.)
3.
Enter the Input/Run level with .
BUS
USB
4.
Select GPIB with , or .
BUS
GPIB
5. Press ENTER to confirm the setting. (The menu reverts to the
Select level.)
(Currently set I/F)
I/F
GPIB BUS
6.
Select GP.Adr (GPIB address) with , or .
(Currently set GPIB address)
I/F
01 GP.Adr
7.
Enter the Input/Run level with .
GP.Adr
01
8.
Select the digit to be changed with or , and set
GP.Adr with , or .
GP.Adr
02
9. Press ENTER to confirm the setting. (The menu reverts to the
Select level.)
(Currently set GPIB address)
I/F
02 GP.Adr
10. Press EXIT to exit the menu.
