ADCMT 6146 - Device Event Status Register (DSR)

6146/6156 DC Voltage/Current Generators Operation Manual
5.6.1 Status Register
5-22
Table 5-6 Device Event Status Register (DSR)
bit Name Description
0 Not in use Always set to 0
1 Not in use Always set to 0
2 Not in use Always set to 0
3 Not in use Always set to 0
4 Not in use Always set to 0
5SUS
Suspend
ON : Set to 1 when Suspend status is set.
OFF : Set to 0 when Operate or Standby status is set.
6LML
Limiter Low
ON : Set to 1 when the LO limit is detected.
7LMH
Limiter High
ON : Set to 1 when the HI limit is detected.
8 ETG
Ext.Trigger In
ON : Set to 1 when an external trigger signal input is detected.
9EOP
Ext.Operate Off In
ON : Set to 1 when an external operating interruption signal input is detected.
10 RDY
READY Out
ON : Set to 1 when the output status is switched from Standby/Suspend to Oper-
ate, or 10 ms (or 50 ms) after the source value is changed in Operate status.
OFF : Set to 0 while the source value is being changed, or when Standby or Sus-
pend status is set.
11 OPR
Operate
ON : Set to 1 when Operate status is set.
OFF : Set to 0 when Standby status is set.
12 CAE
Calibration End
ON : Set to 1 when calibration is complete.
OFF : Set to 0 when calibration starts.
13 SWE
Sweep End
ON : Set to 1 when scan or sweep is complete.
OFF : Set to 0 when scan or sweep starts.
14 SWR
Sweep Run
ON : Set to 1 when scan or sweep starts.
OFF : Set to 0 when scan or sweep is complete or paused.
15 Not in use Always set to 0
