6146/6156 DC Voltage/Current Generators Operation Manual
2.2.3 Menu Operation
2-22
2.2.3.1 How to Operate Menu
Operate the menu in accordance with the following procedure.
1. Press MENU.
The selection screen for the Category level 1..SOURC to 9..SYS appears.
(For the 6146, 1..SOURC to 8..SYS)
2. Select a category with , or .
3. Press to enter the Select level.
4. Select a parameter with , or .
5. Press to enter the Input/Run level.
6. Parameter setting and execution operations differ according to the parameter
type.
Set the parameter with , or .
7. Press MENU or EXIT to exit the menu screen and return to the HOME screen.
Table 2-1 shows the menu and key functions.
NOTE: During sweep or memory scan operation, the MENU key is unavailable.
Table 2-1 Menu and Key Functions
Key Category level Select level
Input/Run level
Numeric
parameter
Select parameter Run
- Go to Category
level
Go to Select level Go to Select level Go to Select level
Go to Select
level
Go to Input/
Run level
-- -
Go to Category
to left
Go to parameter
to left
Move cursor to
left
Change selection -
Go to Category
to right
Go to parameter
to right
Move cursor to
right
Change selection -
Go to Category
to right or left
Go to parameter
to right or left
Increase/decrease
digit at cursor
Change selection -
DATA - - Go to Direct
screen
- Run, go to Select level
MENU Exit menu Exit menu Exit menu Exit menu Run, go to Select level,
exit menu
EXIT Exit menu Exit menu Exit menu Exit menu Exit menu
