6146/6156 DC Voltage/Current Generators Operation Manual
1.5.4 Power Cable
1-8
4. Insert a rated fuse (See Table 1-4).
5. Return the fuse holder assembly into the rear panel.
6. Verify that a rated fuse is installed and that the correct power voltage appears in
the window.
1.5.4 Power Cable
CAUTION:
1. Use a power cable that conforms to the power outlet voltage and type. However, for use outside of Japan, use
only a power cable approved for the respective country.
2. To prevent electric shock, connect the power cable to an outlet with a ground terminal. If an extension cable
without a ground terminal is used, the protective ground feature will be rendered ineffective.
3. Be sure to set the POWER switch on the front panel to OFF before the power cable is connected.
Figure 1-3 Power Cable
Into AC power outlet
Ground pin
3-pin power cable
